404J-22G

Perkins 400 Series

Engine Series	Engine Type	Engine Build	Cylinders	Maximum Power	Maximum Torque
Perkins 400 Series	Genset		4

Rated Speed	Minimum Power	Emissions	Cycle	Bore	Stroke
1500 RPM		EU Stage V		84 mm	100 mm

Displacement	Compression Ratio	Aspiration	Combustion System	Rotation from Flywheel End	Cooling System
2.2 L	23.3:1	Natural	Mechanical Indirect Injection		Watercooled

Length	Width	Height	Dry Weight	Gross Mechanical Output	Typical Electrical Output
973 mm	590 mm	840 mm	242 kg	18.6-20.6 kWm	20.1-22.3 kVA (16.1-17.8 kWe)

Rotation	Alternator Efficiency	Switchable
Counter-Clockwise	87%	No
